DS-2CE56D0T-IRMMF(20m IR)

Camera

• Image Sensor : 2MP CMOS
• Max. Resolution : 1920 (H) × 1080 (V)
• Min. Illumination : 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR
• Shutter Time : PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s
• Day & Night : ICR
• Angle Adjustment : Pan: 0 to 360°, Tilt: 0 to 70°, Rotation: 0 to 360°
• Signal System : PAL/NTSC

Lens

• Lens Type : 2.8 mm, 3.6 mm, 6 mm fixed lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 101°, vertical FOV: 60°, diagonal FOV: 122°

  3.6 mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7°

  6 mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8°

• Lens Mount : M12


• Image Parameters Switch : STD/HIGH-SAT
• Image Settings : Brightness, Sharpness, Smart IR
• Frame Rate : TVI: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps AHD: 1080P@30fps, 1080P@25fps CVBS: PAL/NTSC
• Day/Night Mode : Auto/Color/BW (Black and White)
• Wide Dynamic Range (WDR) : Digital WDR
• Image Enhancement : BLC, HLC
• White Balance : Auto/Manual
• AGC : Yes

Interface

• Video Output : Switchable TVI/AHD/CVI/CVBS

General

• Material : Plastic
• Dimension : Φ 98 mm × 65.4 mm (Φ 3.86″ × 2.57″)
• Weight : Approx. 146 g (0.32 lb.)
• Operating Condition‘ : -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
• Communication : HIKVISION-C
• Language : English
• Power Supply : 12 VDC ± 25%
• Consumption : Max. 1.8 W
• IR Range : Up to 20 m
