EZVIZ 2MP CS-C3TN Outdoor Wi-Fi B&W Camera (2.8mm Lens)

Key Specification of EZVIZ CS-C3TN Outdoor Wi-Fi B&W Camera 2.8mm are as follows.

Model :  EZVIZ CS-C3TN Outdoor Wi-Fi B&W Camera 2.8mm / CS-C3TN(2MP)

Camera

Image Sensor : 1/2.7”Progressive Scan CMOS

Minimum Illumination : 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR

Shutter Speed : Self-adaptive shutter

Lens : 2.8 mm @ F2.0, view angle: 106° (Horizontal), 122°(Diagonal)

Lens Mount : M12

DNR : 3D DNR

WDR : Digital WDR

Compression

Video Compression : H.265 / H.264

Video Bit Rate : Ultra-HD; HD; Standard. Adaptive bit rate.


Max. Resolution : 1920 × 1080

Frame Rate : Max: 30fps; Self-Adaptive during network transmission

Network

Wi-Fi Pairing : AP Pairing

Protocol : EZVIZ Cloud Proprietary Protocol

Interface Protocol : EZVIZ Cloud Proprietary Protocol

General Function :  Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark

Max. Bitrate : 2M

Interface

Storage : Micro SD card slot (Max. 256 GB)

Wired network : RJ45 × 1(10M/100M Adaptive Ethernet Port)

Wi-Fi

Standard : IEEE802.11b, 802.11g, 802.11n

Frequency Range : 2.4GHz ~ 2.4835 GHz

Channel Bandwidth : Supports 20MHz

Security : 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

Transmission Rate : 11b: 11Mbps,11g: 54Mbps,11n: 144Mbps

General

Operating Conditions : -4°F to 122 °F (-20ºC to 50ºC ); Humidity 95% or less ( non-condensing)

Power Supply : DC 12V/1A

Power Consumption : Max. 6W

IP Grade : IP 67

Night Vision Distance (Black/White Night Vision Mode) : Max. 30 m (98 ft)

Dimensions : 72 × 72 × 152 mm (2.83 × 2.83 × 5.98 inch)

Packaging Dimensions : 227 × 100 × 92 mm (8.94 × 3.94 × 3.62 inch)

Net Weight : 253 g (8.9 oz)

In the box

In the box – C3TN Camera

– Drill Template

– Screw Kit

– Waterproof Kit

– Power Adapter

– Regulatory Information

– Quick Start Guide

Certifications

Certifications : CE / FCC / UL / RoHS / WEEE
