Hikvision DS-7104HGHI-M1/T 4CH 2MP/1080p Lite Mini H.265 DVR (Motion Detection+5CH IP Support)
Hikvision DS-7104HGHI-M1/T 4CH 2MP/1080p Lite Mini H.265 DVR (Motion Detection+5CH IP Support) - Image 2
Hikvision DS-7104HGHI-M1/T 4CH 2MP/1080p Lite Mini H.265 DVR (Motion Detection+5CH IP Support) - Image 3

Hikvision DS-7104HGHI-M1/T 4CH 2MP/1080p Lite Mini H.265 DVR (Motion Detection+5CH IP Support)

Hikvision

Hikvision DS-7104HGHI-M1/T 4CH 1080p Lite Mini H.265 DVR a compact and efficient recorder with advanced compression, motion detection, and two-way audio, perfect for CCTV systems in Sri Lanka.

  • Support all channels motion detection technology
  • H.265 Pro+/H.265 Pro/H.265 video compression
  • HDTVI/CVI/AHD/IP/CVBS video inputs
  • Audio over coaxial cable
  • Support all channels HDTVI two-way audio technology
  • Up to 5-ch IP camera inputs

Click to Datasheet of DS-7104HGHI-M1-T

Rs.14,700.00 Rs.22,400.00

Overview – Hikvision DVR in Sri Lanka

The Hikvision DS-7104HGHI-M1/T 4-Channel 1080p Lite Mini H.265 DVR in Sri Lanka is a compact, energy-efficient recorder designed for small to medium surveillance systems.
It supports H.265 Pro+/H.265 Pro/H.265 video compression, reducing storage use while maintaining smooth, clear playback.

This DVR is compatible with HDTVI, AHD, CVI, CVBS, and IP cameras, allowing flexible installation across various CCTV setups.
With support for up to 5 IP channels, you can easily expand your surveillance coverage.
The system also includes motion detection on all channels, enhancing security by triggering recording or alerts only when movement is detected.

Thanks to two-way audio over HDTVI, the DVR supports communication through connected cameras, making it suitable for residential, retail, and business environments.
Its advanced coaxial audio transmission ensures clear sound without extra cabling, providing both convenience and reliability.

Compact yet powerful, the Hikvision DS-7104HGHI-M1/T delivers cost-effective and high-quality video recording for homes, offices, and small businesses in Sri Lanka.

Technical Highlights

  • Channels: 4 Analog + 1 IP Channel (Up to 5 total)

  • Video Compression: H.265 Pro+/H.265 Pro/H.265

  • Video Input: HDTVI/CVI/AHD/IP/CVBS

  • Recording Resolution: 1080p Lite

  • Audio Input: Over Coaxial (HDTVI Two-Way Audio Supported)

  • Motion Detection: Supported on all channels

  • Video Output: HDMI / VGA

  • Playback: 4-channel simultaneous playback

  • Storage: 1 SATA interface for HDD

  • Design: Mini 1U compact metal chassis

  • Power Supply: 12 V DC

Why Choose Hikvision DVR in Sri Lanka

The Hikvision DS-7104HGHI-M1/T 4CH DVR in Sri Lanka offers reliable performance with advanced compression and motion detection.
It’s ideal for users who need clear 1080p recording, low storage use, and easy integration with existing cameras.
Whether for home or commercial setups, it delivers dependable performance, crystal-clear playback, and efficient recording management.

SKU: DS-7104HGHI-M1/T Category:
Weight 1 kg
brands

Hikvision

Motion Detection 2.0

  • Human/Vehicle Analysis

    Deep learning based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;

    Quick search by object or event type is supported;

Video and Audio

  • IP Video Input

    1-ch (up to 5-ch)

    Up to 2MP resolution

    Support H.265+/H.265/H.264+/H.264 IP cameras

  • Analog Video Input

    4-ch

    BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

  • HDTVI Input : 1080p25, 1080p30, 720p25, 720p30
  • AHD Input : 1080p25, 1080p30, 720p25, 720p30
  • HDCVI Input : 1080p25, 1080p30, 720p25, 720p30
  • CVBS Input : Support
  • HDMI Output

    1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

  • VGA Output

    1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

  • Video Output Mode : HDMI/VGA simultaneous output
  • Audio Input

    1-ch RCA (2.0 Vp-p, 1 KΩ)

    4-ch via coaxial cable

  • Audio Output : 1-ch, RCA (Linear, 1 KΩ)
  • Two-Way Audio : Reuse the first audio input
  • Synchronous playback : 4-ch

Recording

  • Video Compression : H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
  • Encoding Resolution

    For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF

    For 720p stream access: 720p/WD1/4CIF/VGA/CIF

    For SD stream access: WD1/4CIF/VGA/CIF

  • Frame Rate

    Main stream:

    For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@25 fps(P)/30 fps (N)

    For 720p stream access: 720p/WD1/4CIF/VGA/CIF@ 25fps (P)/30 fps (N)

    For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

    Sub-stream:

    4CIF@15fps; CIF/QVGA@25 fps (P)/30 fps (N)

  • Video Bitrate : 32 Kbps to 4 Mbps
  • Stream Type : Video, Video & Audio
  • Audio Compression : G.711u
  • Audio Bitrate : 64 Kbps

Network

  • Total Bandwidth : 64 Mbps
  • Network Protocol : TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™, HTTPS
  • Remote Connection : 32
  • Network Interface : 1, RJ45 10/100 Mbps self-adaptive Ethernet interface

Auxiliary Interface

  • SATA : 1 SATA interface
  • Capacity : Up to 4 TB capacity for each disk
  • USB Interface : Rear panel: 2 × USB 2.0
  • Alarm In/Out : N/A

General

  • Power Supply: 12 VDC, 1.5 A
  • Consumption : ≤ 10 W (without HDD)
  • Working Temperature : -10 °C to 55 °C (14 °F to +131 °F)
  • Working Humidity : 10% to 90%
  • Dimension (W × D × H) : 200 × 200 × 48 mm (7.9 × 7.9 × 1.9 inch)
  • ≤ 0.8 kg (without HDD, 1.8 lb.)
