Hikvision Uninterruptible Power Supply (UPS) 1000VA (1kVA + 600W + LED Indicators + Surge Protection)

Overview – Resilient Power Backup & Automated Line Regulation

The Hikvision DS-UPS1000-R Backup UPS provides dependable clean-power distribution and automated equipment protection. Specifically, this line-interactive UPS runs an advanced automatic voltage regulation (AVR) transformer block.

Consequently, it stabilizes high voltage fluctuations across a wide incoming 162VAC to 290VAC grid down to a steady 230VAC supply line. This dynamic regulation loop effectively eliminates system reboots from brownouts or sudden spikes. Therefore, your network hardware or camera recording servers can continue operating smoothly through erratic main grid shifts.

Battery Power and Auto-Restart

The device features a dense 1000VA power rating envelope. Additionally, it carries a highly optimized internal lead-acid storage cell configuration. This battery configuration relies on advanced quick-charge conversion topologies.

Meanwhile, the system deploys an intelligent auto-restart control logic sequence. As a result, it accurately detects incoming line recoveries to power back up autonomously while initiating a super-fast 4-to-6 hour recharge sweep. Thus, your connected critical lines maintain immediate backup readiness during sequential blackouts.

System Safety and Monitoring

Furthermore, this compact unit works as a true hybrid load protection gateway. Specifically, the Hikvision DS-UPS1000-R Backup UPS includes comprehensive hardware monitoring safety layers. This structural setup allows it to defend against severe output short circuits, downstream overloads, and destructive cell over-discharges simultaneously.

Consequently, you can safeguard delicate network video recorders, desktop clients, or commercial storage grids. This unified protection loop lowers your total electronics hardware replacement overhead risks.

System monitoring is simple because of highly intuitive front panel diagnostic arrays. Specifically, you can track current load states using three distinct dedicated color-coded LEDs.

Therefore, site administrators can isolate system faults or battery usage tracking at a glance. You can review charging stages, listen to progressive acoustic alarm steps, and verify active safety channels easily. Consequently, this interface makes routine power system maintenance fast and user-friendly.

Standard Outlets and Backup Time

Additionally, the enclosure supports standard power plug architectures. It interfaces directly with commercial equipment using two built-in standard Schuko output outlets. Because of this, it links smoothly with heavy-duty security supply splitters or direct desktop power blocks.

Specifically, you can connect it directly to professional 12V terminal adapters or central desktop clusters. Therefore, facility technicians can protect essential data nodes without hunting for proprietary adapter connectors.

Moreover, the Hikvision DS-UPS1000-R Backup UPS functions reliably during sudden main grid disconnects. It bridges the transition to backup battery power in under 10 milliseconds via a clean simulated sine wave output.

After that, IT staff can count on 20 to 25 minutes of continuous backup runtime under typical 100W computing loads. The rugged internal control processor automatically cuts power output cleanly before full depth-of-discharge limits are breached. Consequently, your operational team can execute safe desktop shutdowns without risking hard drive database corruption.

⚙️ Key Features

• Integrated Line AVR: Constantly conditions incoming utility lines across 162–290 VAC to block brownouts and heavy voltage spikes.

• Super Fast Charging: Advanced internal charging circuitry replenishes the storage cells up to 90% capacity within 4 to 6 hours.

• Unattended Auto-Restart: Automatically powers back up and feeds connected loads the moment standard AC power returns.

• Full Spectrum Protection: Multi-stage safety breakers defend against overloads, extreme short circuits, surges, and deep cell discharge damage.

• Dual Schuko Outlets: Outfitted with 2 robust, standard Schuko sockets to distribute battery power directly to multiple core devices.

• Acoustic Status Indicators: Emits responsive multi-cadence audio beeps to instantly signal low battery levels, overloads, or fault conditions.

📊 Key Specifications

• Product Class: Line-Interactive Uninterruptible Power Supply (UPS) with Built-in Battery Storage

• Manufacturer Brand: Hikvision

• Model Designation: DS-UPS1000-R

• Official Product Identifier: MPN: DS-UPS1000-R

• Apparent Power Rating: 1000 VA

• Active Power Capacity: 600 W

• Output Power Waveform: Simulated Sine Wave output distribution

• Input Mains Frequency: 50/60 Hz self-adaptive switching sensor logic

Electrical, Battery & Mechanical Metrics

• Input Voltage Range: Wide-tolerance grid compliance running between 162 VAC and 290 VAC

• Output Voltage Accuracy: Regulated 230 VAC ± 10% when operating in standalone inverter battery mode

• Power Transfer Speed: Rapid switching response threshold completing power handovers in ≤ 10 ms

• Battery Configuration: 1 × High-discharge 12 V / 9 Ah sealed lead-acid cell block

• Typical Runtime Metrics: Delivers a reliable 20 to 25 minutes of continuous system backup under a steady 100W hardware load

• Physical Outlet Standard: 2 × Integrated Schuko power distribution sockets

• Diagnostic LED Display: Green LED (Line Mode), flashing Yellow LED (Battery Mode), solid Red LED (System Fault Mode)

• Enclosure Form Factor: 276.1 mm × 101 mm × 142 mm (10.9″ × 3.98″ × 5.59″) compact tower design

• Total Hardware Weight: Balanced 5.55 kg (12.24 lb) chassis mass for stable under-desk or rack placement

• Operating Ambient Bounds: Engineered for peak performance inside 0 °C to 40 °C ambient spaces at 0% to 90% non-condensing humidity

⭐ Why Choose the DS-UPS1000-R Backup UPS?

Choosing the Hikvision DS-UPS1000-R Backup UPS upgrades your hardware infrastructure and guards critical enterprise equipment loops. The built-in heavy-duty AVR block eliminates the need to buy extra external line conditioners or manual voltage stabilizers.

Therefore, connected security gear operates within a tight voltage band, reducing long-term electronics degradation. Furthermore, the robust 10-millisecond transfer velocity prevents sensitive network devices from dropping off during immediate regional blackouts.

Automated Power Recovery

Additionally, the unattended auto-restart capability simplifies property management for remote sites and unmanned offices. The system restores downstream power automatically when the main power grid recovers.

This process runs without requiring an on-site technician to manually press a reset button. Meanwhile, the rapid 4-to-6 hour battery recharge curve ensures the unit is ready to protect your devices even during recurring power cuts. Consequently, these premium electrical protection features keep your vital network loops online without costly interruptions.

Smart Business Protection

Ultimately, this line-interactive UPS delivers maximum business continuity while defending against catastrophic grid surges. It combines a robust 600W power inverter, automatic voltage stabilization, dual power outlets, and smart acoustic fault management into one space-saving tower casing.

Investing in this industrial backup tool guarantees highly reliable hardware protection for your core systems at a very practical price point. Thus, you can run business equipment safely and protect valuable data logs without interruption.
