iDS-7204HUHI-M1/T 4-Channel 5MP 1U H.265 AcuSense DVR (4K/8MP Recording + Facial Detection + Motion Detection 2.0 + Audio Over Coaxial + 10 TB SATA)


Upgrade your surveillance setup with the Hikvision 4 Channel DVR Sri Lanka model, engineered with deep learning AcuSense AI to eliminate false triggers. Furthermore, this compact 1U recorder supports up to 4K/8MP encoding resolution, facial detection, Motion Detection 2.0, and 4-channel audio over coaxial cable. Built with 1 SATA slot holding up to 10 TB storage capacity, it features H.265 Pro+ compression and fast islandwide delivery.

  • Video Channels & Inputs: 4-Ch BNC Analog (HDTVI / AHD / HDCVI / CVBS) + up to 8-Ch IP (Up to 8 MP).

  • Encoding Resolution: 8 MP @ 8 fps (Ch 1), 3K / 5 MP @ 12 fps, and 4 MP @ 15 fps with H.265 Pro+ compression.

  • AI & Video Analytics: Motion Detection 2.0 (All Channels), Facial Detection & Search, and 4-Ch Perimeter Protection.

  • Audio & Storage Capabilities: 4-Ch Coaxial Audio, 1-Ch Two-Way Audio, and 1 SATA HDD slot (Up to 10 TB).

  • Network & Outputs: Simultaneous 2K HDMI / VGA (2560 × 1440), 96 Mbps total bandwidth, and Hik-Connect support.

  • Product Identifier (MPN): iDS-7204HUHI-M1/T

Click to Datsheet of iDS-7204HUHI-M1_T



Rs.44,100.00 Rs.49,058.64

🔒 Overview – High-Capacity Smart Hybrid Surveillance for Intelligent Commercial Security

Are you looking for a dependable Hikvision 4 Channel DVR Sri Lanka system? This advanced recorder is designed to protect your enterprise assets and optimize workforce accountability. Furthermore, the Hikvision 4 Channel DVR Sri Lanka model is housed in a compact 1U chassis with 1 SATA hard drive bay. Therefore, it saves space while offering heavy-duty hardware performance. Moreover, we offer fast islandwide delivery for all buyers.

This highly adaptive unit effectively combines smart hardware with deep learning algorithms. Consequently, it easily addresses modern commercial challenges. Additionally, it cuts down data management overhead and lowers infrastructure cabling costs. In addition, it completely eliminates high-frequency false alarms through Motion Detection 2.0. Thus, this hybrid hub scales effortlessly to keep your property protected 24/7.

⚙️ Key Features of Hikvision 4 Channel DVR Sri Lanka

  • Deep Learning AcuSense Security: The DVR provides high-precision analytics across all channels. Specifically, it separates human targets and vehicle shapes from benign background noise.

  • 4K/8MP Ultra HD Encoding: Encodes up to 8 MP at 8 fps (Ch 1) or 3K/5 MP at 12 fps with H.265 Pro+ compression. Consequently, it delivers ultra-sharp picture details for security audits.

  • Facial Detection & Perimeter Protection: Features facial capture and search alongside 4-channel perimeter protection. As a result, it enhances active boundary monitoring significantly.

  • Audio Over Coaxial Setup: The unit transmits clean digital audio and HD video down the exact same cable on all 4 channels. Therefore, it eliminates extra wiring costs entirely.

  • High HDD Storage Capacity: Equipped with 1 SATA interface supporting up to 10 TB capacity. Consequently, it enables extensive long-term recording archives.

📊 Key Specifications

  • Video Analytics: Motion Detection 2.0 for all analog channels with deep learning classification.

  • Video Inputs: 4 BNC analog channels and up to 8 IP camera connections (up to 8 MP resolution).

  • Recording Streams: Encodes 8 MP, 5 MP, 3K, 4 MP, and 1080p resolutions with H.265 Pro+ compression.

  • Output Interfaces: Simultaneous 2K HDMI and VGA outputs (2560 × 1440 / 60 Hz).

  • Audio Setup: 1 RCA input, 4 coaxial audio channels, 1 RCA output, and 1-ch Two-Way Audio.

  • Network Throughput: 96 Mbps total bandwidth with Hik-Connect app support and ONVIF compatibility.

  • Storage Interface: 1 SATA interface supporting up to 10 TB HDD capacity.

  • General Parameters: Powered by 12 VDC (1.5 A), maximum power consumption ≤ 15 W (without HDD).

🧠 Advanced Deep Learning & AcuSense Technology

This professional recorder stands out as the ultimate choice for modern security setups. First, it incorporates specialized AcuSense deep learning technology. This technology lowers your long-term storage overhead significantly. For example, it filters out false triggers like moving foliage, animals, or rainfall. Thus, you get clear evidence and accurate target alerts.

🔍 Intelligent Target Search & Coaxial Efficiency

Second, the built-in facial detection and quick search capabilities change how you manage security alerts. Specifically, it filters through hours of footage in seconds to locate specific individuals or vehicle events. As a result, your team spends time reacting to genuine security events. Therefore, they will not waste hours auditing false alarms.

Finally, the system eliminates expensive copper wiring bottlenecks. It runs both synchronized video and clean digital audio over your existing coaxial cables. Furthermore, when combined with universal 5-in-1 hybrid compatibility (TVI, AHD, CVI, CVBS, IP), it lets you maintain your current setup while expanding capability over time.

🌐 Seamless System Integration & Remote Access

Additionally, the system is fully integrated into the secure Hik-Connect platform. Hence, it bridges professional tracking with seamless remote monitoring. Consequently, you can enjoy full control from anywhere in Sri Lanka, with fast islandwide delivery to your doorstep.

SKU: iDS-7204HUHI-M1/T Category:
Weight 3 kg

Facial Detection

  • Facial Detection and Capture : Face picture detection, face picture search

Motion Detection 2.0

  • Human/Vehicle Analysis

    Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights.

    Quick search by object or event type is supported.

Video and Audio

  • IP Video Input

    2-ch (up to 6-ch)

    Enhanced IP mode on:

    4-ch (up to 8-ch), each up to 4 Mbps

    Up to 8 MP resolution

    Support H.265+/H.265/H.264+/H.264 IP cameras

  • Analog Video Input

    4-ch

    BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

  • HDTVI Input : 8 MP(3840 × 2160)@12/15 fps, 3K(2960 x 1665)@25/20 fps,3K(3328×1504)@20 fps,2K(2304 x 1296)@20 fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • AHD Input : 5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • HDCVI Input : 8 MP(3840 × 2160)@12/15 fps, 3K(2880×1620)@20/25 fps, 5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • CVBS Input : PAL/NTSC
  • HDMI Output : 1-ch, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
  • VGA Output : 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
  • Video Output Mode : HDMI/VGA simultaneous output
  • Audio Input

    1-ch, RCA (2.0 Vp-p, 1 KΩ)

    4-ch via coaxial cable

  • Audio Output : 1-ch, RCA (Linear, 1 KΩ)
  • Two-Way Audio : 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
  • Synchronous Playback : 4-ch

Recording

  • Video Compression : H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
  • Encoding Resolution : 8 MP/5 MP/3K/4 MP/3 MP/2K/1080p/720p/WD1/4CIF/VGA/CIF
  • Frame Rate

    Main stream:

    8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps/2K@20 fps

    1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

    *: 8 MP@8 fps is only available for channel 1, 8 MP Lite is only available for channel 2 to channel 4.

    Sub-stream:

    WD1/4CIF/CIF@25 fps (P)/30 fps (N)

  • Video Bitrate : 32 Kbps to 10 Mbps
  • Dual-stream : Support
  • Stream Type : Video, Video & Audio
  • Audio Compression : G.711u
  • Audio Bitrate : 64 Kbps

Network

  • Total Bandwidth : 96 Mbps
  • Remote Connection : 32
  • Network Protocol : TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP
  • Network Interface : 1, RJ45 10/100 Mbps self-adaptive Ethernet interface
  • Wi-Fi : Connectable to Wi-Fi network by Wi-Fi dongle through USB interface

Auxiliary Interface

  • SATA : 1 SATA interface
  • Capacity : Up to 10 TB capacity for each disk
  • Alarm In/Out : N/A
  • USB Interface : 2 × USB 2.0

General

  • Power Supply : 12 VDC, 1.5 A
  • Consumption : ≤ 15 W (without HDD)
  • Working Temperature : -10 °C to +55 °C (+14 °F to +131 °F)
  • Working Humidity : 10% to 90%
  • Dimension (W × D × H) : 263 × 225 × 48 mm (10.3 × 8.8 × 1.9 inch)
  • ≤ 1.16 kg (without HDD, 2.6 lb.)
